Product Details

Quick Details
Specifications

Place of Origin: CANGZHOU
Brand Name: xinlian
Model Number: API 5CT

Casing pipe is most often used in underground construction projects to encase or protect utility lines from being damaged.

Once a well has been drilled, if it is to become a production well, the well must undergo completion. While drilling a well cuts through the rock formations and allows drilling engineers to reach the reservoir below, the raw sides of the well cannot support themselves. Similar to the bones of your spine protecting the spinal cord, casing is tubing that is set inside the drilled well to protect and support the wellstream.

1.Specification range:OD: 42.16 MM - 114.3 MM(1.66"--4 1/2") WT: 3.56MM-9.52MM(2.3PPF--12.95PPF)

2. Materials: H40, J55, K55, N80-1, N80-Q, L80-1,L80-9Cr, L80-13Cr, P110, Q125 etc

3. Executive standards: API 5CT, GB, ISO11960, GOST

4. Thread connection: NU, EU，IJ

5. Length: R1, R2, R3

6. Testing: NDT etc related rules of API 5CT and 5B

7:Type:seamless pipe

Place of Origin: CANGZHOU
Brand Name: xinlian
Model Number: API 5CT

Sizes		OD D mm	Weight kg/m	WT t mm	Type of end
Sizes					H40	J55 K55	M65	L80 C95	N80 1、Q	C90 T95	P110	Q125
1	2				H40	J55 K55	M65	L80 C95	N80 1、Q	C90 T95	P110	Q125
1	2	3	4	5	6	7	8	9	10	11	12	13
4-1/2 4-1/2 4-1/2 4-1/2 4-1/2	9.50 10.50 11.60 13.50 15.10	114.30 114.30 114.30 114.30 114.30	14.14 15.63 17.26 20.09 22.47	5.21 5.69 6.35 7.37 8.56	PS - - - -	PS PSB PSLB - -	PS PSB PLB PLB -	- - PLB PLB -	- - PLB PLB -	- - PLB PLB -	- - PLB PLB PLB	- - - - PLB
5 5 5 5 5 5 5	11.50 13.00 15.00 18.00 21.40 23.20 24.10	127.00 127.00 127.00 127.00 127.00 127.00 127.00	17.11 19.35 22.32 26.79 31.85 34.53 35.86	5.59 6.43 7.52 9.19 11.10 12.14 12.70	- - - - - - -	PS PSLB PSLBE - - - -	PS PSLB PLB PLB PLB - -	- - PLBE PLBE PLB PLB PLB	- - PLBE PLBE PLB PLB PLB	- - PLBE PLBE PLB PLB PLB	- - PLBE PLBE PLB PLB PLB	- - - PLBE PLB PLB PLB
5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2 5-1/2	14.00 15.50 17.00 20.00 23.00 26.80 29.70 32.60 35.30 38.00 40.50 43.10	139.70 139.70 139.70 139.70 139.70 139.70 139.70 139.70 139.70 139.70 139.70 139.70	20.83 23.07 25.30 29.76 34.23 39.88 44.20 48.51 52.53 56.55 60.27 64.14	6.20 6.98 7.72 9.17 10.54 12.70 14.27 15.88 17.45 19.05 20.62 22.22	PS - - - - - - - - - - -	PS PSLBE PSLBE - - - - - - - - -	PS PSLB PLB PLB PLB - - - - - - -	- - PLBE PLBE PLBE - - - - - - -	- - PLBE PLBE PLBE - - - - - - -	- - PLBE PLBE PLBE P P P P P P P	- - PLBE PLBE PLBE - - - - - - -	- - - - PLBE - - - - - - -
6-5/8 6-5/8 6-5/8 6-5/8	20.00 24.00 28.00 32.00	168.28 168.28 168.28 168.28	29.76 35.72 41.67 47.62	7.32 8.94 10.59 12.06	PS - - -	PSLB PSLBE - -	PSLB PLB PLB -	- PLBE PLBE PLBE	- PLBE PLBE PLBE	- PLBE PLBE PLBE	- PLBE PLBE PLBE	- - - PLBE
7 7 7 7 7 7 7	17.00 20.00 23.00 26.00 29.00 32.00 35.00	177.80 177.80 177.80 177.80 177.80 177.80 177.80	25.30 29.76 34.23 38.69 43.16 47.62 52.09	5.87 6.91 8.05 9.19 10.36 11.51 12.65	PS PS - - - - -	- PS PSLBE PSLBE - - -	- PS PLB PLB PLB PLB -	- - PLBE PLBE PLBE PLBE PLBE	- - PLBE PLBE PLBE PLBE PLBE	- - PLBE PLBE PLBE PLBE PLBE	- - - PLBE PLBE PLBE PLBE	- - - - - - PLBE
7 7 7 7 7 7	38.00 42.70 46.40 50.10 53.60 57.10	177.80 177.80 177.80 177.80 177.80 177.80	56.55 63.54 69.05 74.56 79.77 84.97	13.72 15.88 17.45 19.05 20.62 22.22	- - - - - -	- - - - - -	- - - - - -	PLBE - - - - -	PLBE - - - - -	PLBE P P P P P	PLBE - - - - -	PLBE - - - - -
7-5/8 7-5/8 7-5/8 7-5/8 7-5/8 7-5/8 7-5/8 7-5/8 7-5/8 7-5/8	24.00 26.40 29.70 33.70 39.00 42.80 45.30 47.10 51.20 55.30	193.68 193.68 193.68 193.68 193.68 193.68 193.68 193.68 193.68 193.68	35.72 39.29 44.20 50.15 58.04 63.69 67.41 70.09 76.19 82.30	7.62 8.33 9.52 10.92 12.70 14.27 15.11 15.88 17.45 19.05	PS - - - - - - - - -	- PSLBE - - - - - - - -	- PSLB PLB PLB - - - - - -	- PLBE PLBE PLBE PLBE PLB PLB PLB - -	- PLBE PLBE PLBE PLBE PLB PLB PLB - -	- PLBE PLBE PLBE PLBE PLB PLB PLB P P	- - PLBE PLBE PLBE PLB PLB PLB - -	- - - - PLBE PLB PLB PLB - -
7-3/4	46.10	196.85	68.60	15.11	-	-	-	P	P	P	P	P
8-5/8 8-5/8 8-5/8 8-5/8 8-5/8 8-5/8 8-5/8	24.00 28.00 32.00 36.00 40.00 44.00 49.00	219.08 219.08 219.08 219.08 219.08 219.08 219.08	35.72 41.67 47.62 53.57 59.53 65.48 72.92	6.71 7.72 8.94 10.16 11.43 12.70 14.15	- PS PS - - - -	PS - PSLBE PSLBE - - -	PS PS PSLB PSLB PLB - -	- - - PLBE PLBE PLBE PLBE	- - - PLBE PLBE PLBE PLBE	- - - PLBE PLBE PLBE PLBE	- - - - PLBE PLBE PLBE	- - - - - PLBE
9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8 9-5/8	32.30 36.00 40.00 43.50 47.00 53.50 58.40 59.40 64.90 70.30 75.60	244.48 244.48 244.48 244.48 244.48 244.48 244.48 244.48 244.48 244.48 244.48	48.07 53.57 59.53 64.73 69.94 79.62 86.91 88.40 96.58 104.62 112.50	7.92 8.94 10.03 11.05 11.99 13.84 15.11 15.47 17.07 18.64 20.24	PS PS - - - - - - - - -	- PSLB PSLBE - - - - - - - -	- PSLB PSLB PLB PLB - - - - -	- - PLBE PLBE PLBE PLBE PLB - - - -	- - PLBE PLBE PLBE PLBE PLB - - - -	- - PLBE PLBE PLBE PLBE PLB P P P P	- - - PLBE PLBE PLBE PLB - - - -	- - - - PLBE PLBE PLB - - - -
10-3/4 10-3/4 10-3/4 10-3/4 10-3/4 10-3/4 10-3/4	32.75 40.50 45.50 51.00 55.50 60.70 65.70	273.05 273.05 273.05 273.05 273.05 273.05 273.05	48.74 60.27 67.71 75.90 82.59 90.33 97.77	7.09 8.89 10.16 11.43 12.57 13.84 15.11	PS PS - - - - -	- PSB PSBE PSBE - - -	- PSB PSB PSB PSB - -	- - - PSBE PSBE - -	- - - PSBE PSBE - -	- - - PSBE PSBE PSBE PSB	- - - PSBE PSBE PSBE PSB	- - - - - PSBE PSB
10-3/4 10-3/4 10-3/4	73.20 79.20 85.30	273.05 273.05 273.05	108.93 117.86 126.94	17.07 18.64 20.24	- - -	- - -	- - -	- - -	- - -	P P P	- - -	- - -
11-3/4 11-3/4 11-3/4 11-3/4 11-3/4 11-3/4	42.00 47.00 54.00 60.00 65.00 71.00	298.45 298.45 298.45 298.45 298.45 298.45	62.50 69.94 80.36 89.29 96.73 105.66	8.46 9.53 11.05 12.42 13.56 14.78	PS - - - - -	- PSB PSB PSB - -	- PSB PSB PSB - -	- - - PSB P P	- - - PSB P P	- - - PSB P P	- - - PSB P P	- - - PSB P P
13-3/8 13-3/8 13-3/8 13-3/8 13-3/8	48.00 54.50 61.00 68.00 72.00	339.72 339.72 339.72 339.72 339.72	71.43 81.10 90.78 101.19 107.15	8.38 9.65 10.92 12.19 13.06	PS - - - -	- PSB PSB PSB -	- PSB PSB PSB -	- - - PSB PSB	- - - PSB PSB	- - - PSB PSB	- - - PSB PSB	- - - - PSB
16 16 16 16	65.00 75.00 84.00 109.00	406.40 406.40 406.40 406.40	96.73 111.61 125.01 162.21	9.53 11.13 12.57 16.66	PS - - -	- PSB PSB P	- PSB PSB -	- - - P	- - - P	- - - -	- - - P	- - - P
18-5/8	87.50	473.08	130.21	11.05	PS	PSB	PSB	-	-	-	-	-
20 20 20	94.00 106.50 133.00	508.00 508.00 508.00	139.89 158.49 197.93	11.13 12.70 16.13	PSL - -	PSLB PSLB PSLB	PSLB PSLB -	- - -	- - -	- - -	- - -	- - -
Remarks: P——Plain end;S—Short round thread;L—Long round thread;B—Buttress thread;E—Extreme-line.
